Standard&Protocol
IEEE802.3, IEEE802.3u,IEEE802.3ab
Interfaces
1*10/100Mbps WAN port
3*10/100Mbps LAN ports
Antenna
3*5dBi external antennas
Button
1*RST
Power
Input：AC 100-240V~50/60Hz 0.6A
Output：DC 9V0.6A
Dimension
185*185*27mm
LED Indicator
SYS*1
Wireless
Wireless Standard
IEEE 802.11b/g/n 2.4GHz
Data Rate
2.4GHz: Up to 300Mbps
Frequency
2.4GHz
Transmission Power
CE:<20dBm
Basic Features
WiFi On/Off
Wireless Security
WPA/WPA2, WPA-PSK/WPA2-PSK
Software
Internet Connection Type
PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Operating Mode
Wireless Router Mode
Universal Repeater Mode
WISP Mode
AP Mode
DHCP Server
DHCP Server
DHCP Client List
DHCP Reservation
Virtual Server
Port Forwarding
DMZ Host
UPnP
Security
Client Filter
Parental Control(support black list and white list)
Remote Web Management
Firewall
Forbid UDP flood attack
Forbid TCP flood attack
Forbid ICMP attack
Forbid WAN PING from internet
DDNS
no-ip,DynDNS,Oray
VPN
IPsec pass through
PPTP pass through
L2TP pass through
Special Features
Smart WiFi Schedule
Others
Bandwidth Control
MAC Clone
System Log
Backup & Restore configurations
Firmware upgradeable via browser
Others
Temperature
Operating Temperature: 0℃ ~ 40℃
Storage Temperature: -40℃ ~ 70℃.
Humidity
Operating Humidity:10% ~ 90% RH non-condensing
Storage Humidity: 5% ~ 90%RH non-condensing.
Default Settings
Default Access: 192.168.0.1
Certification
CE/FCC/RoHS
EIRP Power (Max)
2.400-2.4835GHz:19.37dBm (EIRP)
Package Contents
Wireles Router*1
Power Adapter *1
Install Guide*1
Ethernet Cable*1
